Copper Wire Rod Our Copper Wire Rod is manufactured from high-purity copper cathode (Grade A) using the Continuous Casting and Rolling (CCR) process. It offers excellent electrical conductivity, a bright and oxide-free surface, and is ideal for use in wire and cable manufacturing, industrial conductors, and electrical applications. Strict quality control is applied at every production stage, and a chemical and physical analysis report can be provided for each production batch. The rods are available in 6 mm and 8 mm diameters, supplied in 2–4 ton coils.
| Specification | Details |
|---|---|
| Product Name | Copper Wire Rod |
| Alloy / Grade | Cu-ETP (Electrolytic Tough Pitch Copper) |
| Production Standard | ASTM B49 / EN 1977 / ISIRI 4231 |
| Copper Purity | Min. 99.90% Cu |
| Electrical Conductivity | ≥ 100% IACS (58 MS/m) |
| Electrical Resistivity at 20°C | ≤ 0.01724 Ω·mm²/m |
| Wire Diameter | 6 mm and 8 mm |
| Coil Weight | Approx. 2–4 tons (customizable upon request) |
| Surface Quality | Bright, oxide-free, without surface cracks |
| Density | 8.89 g/cm³ |
| Melting Point | 1083°C |
| Applications | Power cables, enamel wires, industrial conductors, electronics, etc. |
| Packaging | In coils, strapped with steel or plastic bands, wrapped in protective film |
| Production Method | Continuous Casting and Rolling (CCR) using copper cathode |
